Feature
|
Description
|
Intel Core i3-7100U
|
Intel HD Graphics 620
2.4 GHz, 3 MB cache, 2 cores
|
Intel Core i5-7200U
|
Intel HD Graphics 620
2.5 GHz, up to 3.1 GHz with Intel Turbo Boost Technology1, 3 MB cache, 2 cores
|
Intel Core i5-7300U
|
Intel HD Graphics 620
2.6 GHz, up to 3.5 GHz with Intel Turbo Boost Technology1, 3 MB cache, 2 cores
vPro support
|
Intel Core i7-7600U
|
Intel HD Graphics 620
2.8 GHz, up to 3.9 GHz with Intel Turbo Boost Technology1, 4 MB cache, 2 cores
vPro support
|
Chipset
|
Integrated with processor
|
Graphics
Feature
|
Description
|
Graphics
|
Intel HD Graphics 620
|
Display
Feature
|
Description
|
Internal
|
31.24 cm (12.3 in) diagonal BrightView LED-backlit better than QHD UWVA eDP 1.3 Ultra-slim (2736 x 1824) touch screen chemically-strengthened Corning Gorilla Glass 4 top cover directly bonded to display
Refresh rate: 60 Hz
Brightness: 450 nits (maximum)
Pixel resolution format: 2736 x 1824 (better than QHD)
Pixel resolution configuration: RGB stripe
Interface: eDP 1.3
LCD mode: IPS/FFS/VA
PPI: 268 PPI
Viewing angle: UWVA 85/85/85/85 (left/right/down/up)
NOTE: |
External
|
24-bit with 8-bit alpha channel (standard)
Up to 30-bit per pixel color depth (wide color gamut)
|
Storage and drives
Feature
|
Description
|
Internal storage
|
Supports M.2 solid state drive SS 2280
128 GB SATA-3 SS value solid state drive
256 GB 2280 M2 PCIe-3x4 solid state NVMe TLC
256 GB 2280 M2 SATA-3 self-encrypted OPAL 2 TLC
256 GB 2280 PCIe NVMe Value
360 GB 2280 PCIe-3x4 NVMe TLC
512 GB 2280 M2 PCIe-3x4 solid state NVMe TLC
512 GB 2280 PCIe NVMe Value
512 GB 2280 M2 SATA-3 Three Layer Cell Federal Information Processing Standard (FIPS 140.2 available via CIS only)
1024 GB 2280 PCIe-3x4 NVMe TLC
|
Expansion storage
|
Micro SD media reader slot: Supports microSD, microSDHC, microSDXC, supporting expansion up to 2 TB
|
